Cell Chemistry
Cell Configuration
Nominal Capacity(Ah)
Nominal Voltage(V)
Nominal Energy(Wh)
Voltage Range(V)
Cycle Life
LiFePO4 prismatic cell
4S1P
150Ah @0.5C discharge rate
12.8V
1920Wh
10-14.6V
6000 cycles DOD80% 0.2C/0.5C
Standard Charge Current(A)
Max. Charge Current(A)
Charge Condition
0.2C(CC-CV)
150A
@-10℃~55℃
Standard Discharge Current(A)
Max. Continuous Discharge Current(A)
Peak Discharge Current(A)
Discharge Condition
0.5C(Constant current discharging)
150A
-
@-10~60℃
Safety Function
Communication
Heating System(optional)
Overcharge,over-discharge,over-current and temperature protection
Available upon requirements (UART / RS485 / CANBUS)
Available upon requirements
Size
Weight
Enclosure
Terminals/Interfaces
330*172*215 mm
12.99*6.77*8.46 in
16.4±1 kg
36.2±2.2 lbs
ABS Case, IP67
M8
Maintenance
Storage Condition @-20~25℃
Storage Condition @-20~45℃
The battery pack should be fully charged every 3 months.
Can be kept for 3 months at 50% capacity
Can be kept for 1 month at 50% capacity
